- Cutting work could be done by only press button after fixing panel, easy and fast.
- Accurate ruler and guiding device cooperated well to fix work piece in proper position as per requirement for accurate cutting work.
- Stop position of saw carriage could be adjusted by rotating the button based on panel size, reducing unnecessary travel stroke for higher efficiency.
|
| |
 |
|
 |
|
|
| Ease of operation |
|
Back view |
|
|
|
| |
Technician Data
|
| Model |
MJB1333B |
| Cutting length |
3300mm |
| Cutting thickness |
76mm |
| Main saw rotating speed |
4200rpm |
| Scoring saw rotating speed |
6500rpm |
| Saw carriage forward speed |
0-45 m/min |
| Saw carriage backward speed |
80 m/min |
| Main saw motor |
11kw |
| Saw carriage driven motor |
1.5kw |
| Air blower |
2.2kw |
| Dust extraction |
φ150mm×3 |
| Total power |
14.7kw |
| Overall size |
5830×3950×1700mm |
| Net weight |
2950kg |
|
|
